Conversion Chart

Conversion Chart

NOTE:

When converting down in rim sizes, as 24" to 20", make sure rim will clear over hub.

Forestry tire assemblies available on request
Call us for the details
Toll Free: 1-800-899-5535

MAKE__________

MODEL________

2 OR 4 WHEEL DRIVE

SER NO._____________

LOCATION__________________

	FRONT	REAR
A. RIM SIZE............................................	___________	___________
B. BOLT HOLE .......................................	___________	___________
C. STUD SIZE.........................................	___________	___________
D. NUMBER OF BOLT HOLES............	___________	___________
E. BOLT HOLE CIRCLE DIAMETER...	___________	___________
F. COUNTERSUNK................................	___________	___________
G. CENTERHOLE DIAMETER.............	___________	___________
H. CENTERPLATE SETTING (FROD).	___________	___________
I. TIRE SIZE.............................................	___________	___________
J. CLEARENCE FROM VEHICLE.........	___________	___________
K. REMARKS..........................................	___________	___________
